6000psi Ss Oxygen Pressure Regulator Diaphragm Transmission

Name: 6000psi Ss Oxygen Pressure Regulator Diaphragm Transmission
Brand: yunyi
Price: 1 USD

China 6000psi Ss Oxygen Pressure Regulator Diaphragm Transmission wholesale

Brand Name : yunyi

Model Number : YR32

Certification : ce

Place of Origin : china

MOQ : 1

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 10000pcs/month

Delivery Time : 10days

Material : Stainless steel

Maximum input pressure : 6000 psi

Safety test pressure : 1.5 times max inlet pressure

Applicable temperature : -40℉~+165℉(-40℃~+74℃)

CV value : 0.02, 0.06, 0.08, 0.2

Weight : About 1.5kg

Outlet pressure : 0-250psig, 0-500psig, 0-1500psig, 0-3000psig

Contact Now

High pressure Stainless Steel air fuel oxygen pressure regulator

Description High pressure Stainless Steel air fuel oxygen pressure regulator

YR32 series back pressure regulator is with single-stage diaphragm vacuum structure, stainless steel diaphragm pressure transmission, the output pressure is stable, suitable for pure gases, standard gases, corrosive gases, liquids and other medium.

Detailed Images High pressure Stainless Steel air fuel oxygen pressure regulator

6000psi Ss Oxygen Pressure Regulator Diaphragm Transmission

Specification High pressure gas back pressure valve regulator for industrial field

The maximum input pressure: 6000 psi

Safety test pressure: 1.5 times max inlet pressure

Applicable temperature: -40℉~+165℉(-40℃~+74℃)

Leak rate: 2x10-8 atm cc/sec He

CV value: 0.2

Weight: About 1.5 kg

Package size: 17cm*17cm*17cm

Material: Stainless steel.

Applications gas back pressure regulator for industrial field

Laboratory, Gas chromatograph, Gas lasers, Gas bus, Petrochemical industry, Test Equipment

Selection Guide gas back pressure regulator for industrial field

Model

Valve material

Inlet pressure

Pressure gauge

Inlet port

Outlet port

YR32

316L

0-500psig

0-100psig

0-1500psig

0-2500psig

0-3000psig

l With gauge (mpa)

l With gauge (psig/bar)

l Without gauge

1/4'' NPT(F)

3/8'' NPT(F)

1/2'' NPT(F)

1/2'' NPT(M)

3/8'' fitting

1/2'' fitting

Or custom

1/4'' NPT(F)

3/8'' NPT(F)

1/2'' NPT(F)

1/2'' NPT(M)

3/8'' fitting

1/2'' fitting

Or custom

6000psi Ss Oxygen Pressure Regulator

Diaphragm Transmission Oxygen Pressure Regulator

17cm Oxygen Pressure Regulator

6000psi Ss Oxygen Pressure Regulator Diaphragm Transmission Images
